1.1TechnicalSpecifications
TheSolarBlocks and the Ecomodels for highvolumewaterheating (HVWH) ENERGIE are on
themarketinarangewith4,6,8,12,16,24,32or40solarpanelsaccordingtothefollowing:
CentralHeating/SwimmingPoolHeating
Model NrofPanels AbsorbedPower SuppliedPower Flow(m
3
/h)
SolarBlock4 4 960W 7,290W 0.5
SolarBlock6 6 1,230W 9,680W 0.7
SolarBlock6 8 1,440W 11,240W 0.8
SolarBlock12 12 2,010W 16,580W 1.0
SolarBlock16 16 3,210W 24,210W 1.5
SolarBlock24 24 4,140W 31,430W 2.8
SolarBlock32 32 5,690W 42,600W 4
SolarBlock40 40 7,630W 52,970W 5
HVWH
Model
Capacity
(L)
NrofPanels
Dim.HotWaterCylinder
Absorbed
Power
Thermal
Power
Height
(mm)
Diameter(mm)
ECO500 500 2 1830 650 595W 2,800W
ECO750 750 4 2135 750 960W 7,290W
ECO1000 1000 4 2185 850 960W 7,290W
ECO1500 1500 6 2460 950 1,230W 9,680W
ECO2000 2000 8 2520 1100 1,440W 11,240W
ECO3000 3000 12 2900 1250 2,010W 16,580W
ECO3000E 3000 16 2900 1250 3,210W 24,210W
ECO4000 4000 24 2960 1450 4,140W 31,430W
ECO5000 5000 32 3030 1600 5,690W 42,600W
ECO6000 6000 40 2x2900 2x1250 7,630W 52,970W
2.0SystemComponents
TheThermodynamicSolarSystemsarecomposedbythefollowingelements:
o ThermodynamicBlock
o ThermodynamicSolarPanels
o LiquidDistributor
