5
2.1ThermodynamicBlock
TheThermodynamicBlockiscomposedofseveralelementssuchas:
o Cabinet
o HermeticcompressorScrolltype
o Heatexchanger*
o Expansionvalve
o Oilseparator
o Fluidtank
o Filter
o Fluiddisplay
o Pressuregauge
o Digitalthermostat
o Electricalequipment
*‐titaniumheatexchangersgoapartfromthethermodynamicblock.
2.2SolarPanel
The solar panel is made of anodized
aluminium of dual rail with post pressing
anodicoxidationforhighsolarabsorption.
The dimensions of the panel are 2000 mm x
800mmx20mm,anditfeaturesafluidflux
inandoutmadeofacopper/aluminiumtube
with inner
diameter of ¼’’. It weights
approximately8kg.
While transporting the collector prote cted it
against impact and mechanical actions, therefore proper packaging upon transportation is
recommended.
2.3FluidDistributor
Toensurethat the fluidreachesthepanelin
aseamlessmanner,it'snecessarytoinstalla
fluid distributor. This distributor features as
many distribution tubes as the number of
panelsintheinstallation.
Thedistributorisplacedbetweenthepanels.
The connection tubes to the panels must
have
the exact same length and its ends are
directlyconnectedtothepanels.
Dimensions[mm] A B C
ThermodynamicBlockfrom4to16panels 880 630 430
ThermodynamicBlockfrom24to40panels 880 750 500
SolarPanel
Serpentinedetail
