The hard drive jumper settings
should be master or factory
default.
Be careful not to damage any
cables or components and
double check the connection
between the cables, the
bridgeboard and your hard
drive before you close up the
case.
Hard Drive Assembly
Connect your SATA hard drive to the connector. Place the hard drive on the 2 mounting pins with
mounting holes under the hard drive.
- 5 -
