3. VLCD-5 Wire System Legend
4. Function Description
Speed display: Shows current speed in Km/h or Mile/h (switchable).
Battery state indicator: Four horizontal bars show the state of battery charge (each bar
stands for about 25% of remaining capacity); flickers to remind you to charge the battery.
Trip distance: Shows the trip distance, can be manually reset. Resets when the system is
switched off.
Comulative distance (ODO): Shows total distance from initial use of the sytem.
Trip time: Shows how long the bike has been in use (for specific trip).
Avarage speed: Shows the average speed.
Power assist: Indicates the power assist level. There are 4 levels: Turbo, Speed, Tour Eco.
Backlight: Switch between 2 levels of brightness, default is backlight off.
Wheel diameter setting: Select wheel-diameter between 14 - 32 inch. Default is 26 inch.
Speed sensor setting: Select the number of the magnets used for the speed sensor, default
value is 1.
Speed unit: Switch between speed units, Km/h or Mile/h.
6km/h throttle setting: Select function of 6km, default is OFF.
Maximum speed setting: Select maximal speed between 15 km/h and 45km/h; Default is
25Km/h.
Assist ratio setting (reserved): Select the ratio; Default is 16.
Zone setting (reserved): Select the area. Default is Europe.
Speed limit setting: default is ON.
Software version: Shows the current version of the device’s software.
Error code: When the kit is powered up, the system runs a self check up. If there are any
issues, a corresponding error code will be shown on the screen.
Torque signal value (reserved): Torque signal value displays.
Initial torque value (reserved): Initial torque signal value displays.
