Enertech Bentone B 2 Series - Model B 2 KA; Model B 2 KAV; Burner Output; Setting the Ignition Electrodes

7 Bentone B 2
General
2,7-3,3
8,0-9,0
0,5-1,5
ø76
ø78
ø22
-
0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
20,0 40,0 60,0 80,0 100,0 120,0
Burner output kW
Boiler overpressure mbar
1.2 Model B 2 KA / Model B 2 KAV
1.2.1 Burner output
2,4 - 9,0 kg/h
28,5 - 106,7 kW
Length of blast tube
mm
Protrusion from flange,
measurement B mm
147 122
197 172
1.2.2 Setting the ignition electrodes
Proper setting of the electrodes is essential to ensure satisfactory operation
of the burner. If the spark hits the metal the efficiency will be lower and will
also cause radio disturbance. There is also a risk that carbonisation will
occur. Since the electrode pack is of the factory-set twin electrode type it will
be necessary to bend the wires to make any adjustment.
