VOICE DIALER Installation Manual
SECO-LARM U.S.A., Inc.Page 4
SETTING THE DIP SWITCHES
1. DIP SWITCH #1 — EXIT DELAY TIME
a. ON (INSTANT) — When set to the OPERATE mode, the E-920A will dial the
programmed numbers immediately when triggered.
b. OFF (DELAY) — When set to the OPERATE mode, the E-920A will allow 120
seconds to pass before it can be triggered. This gives the user time to leave the
protected premises without triggering the voice dialer.
2. DIP SWITCH #2 — ENTRANCE DELAY TIME
a. ON (INSTANT) — When triggered while in the OPERATE mode, the E-920A will
immediately dial the programmed number (after any exit delay has passed).
b. OFF (DELAY) — When triggered while in the OPERATE mode, the E-920A will
wait 30 seconds after being triggered before dialing the programmed numbers.
This gives the user time to turn off the E-920A before the voice dialer triggers
when entering a protected premises.
Note — Unless the user requires extra time, if the E-920A is being used with an
alarm panel which has a programmed entry/exit delay, both DIP switches should be
placed in the "ON" position, which provides an instant response to any trigger.
3. DIP SWITCH #3 — TELEPHONE DIAL-OUT TYPE
a. ON — Pulse/rotary phone
b. OFF — Touch-tone phone
4. DIP SWITCH #4 — TYPE OF TELEPHONE SYSTEM
a. ON — PBX phone system — The E-920A will wait for the dial tone after the first
digit in the telephone number (the dial-out code) is sent. Once the dial tone is
received, the E-920A will send the remaining digits in the number.
b. OFF — Regular phone system — All the digits in the number will be dialed, with
no initial pause.
5. DIP SWITCH #5 — TRIGGER INPUT #1 AND #2 TIMING
Timing for trigger input #1 and trigger input #2 function the same.
a. ON — The E-920A will dial all programmed telephone numbers two times when
triggered by trigger input #1 or input #2, regardless of whether the trigger
signal (from the alarm control panel) is reset or not. This function also works
with any non-timed (momentary) trigger device.
b. OFF — If the triggered input is reset, the dialing action stops. If used with
trigger devices other than an alarm control panel, a timer may be required.
6. DIP SWITCH #6 — NOT USED
