The gas actuator will move to a fully closed (90°) position and read 2V. Set the ball valve to fully closed
mechanically and tighten linkage. The feedback must be at or very near 2V. Record the feedback in the space
provided.
Press in sequence from low to high fire. At each stage enter the feedback values for the gas actuator.
Once complete, press Start Setup to release, and navigate to the Burner setup tab.
Enable the heat switch. Press Service Mode, then set Service Override to 100%.
The ball valve will move to 100% open. Adjust the appliance regulator to achieve the design manifold pressure.
Clock the gas flow and adjust as necessary.
Set Service override to 4%. Set low fire by adjusting the gas offset valve next to the Low Fire window, under
Gas Offsets. The flame should be as small as possible while still maintaining a stable flame across the entire
burner.
Press: Setup Complete.
Press to disable Service Mode.
Navigate to the Save Load tab and press Save Settings.
