EngA ENGINEERED AIR base - DG-HT Series 20:1 Turndown

base A
43
IOM74 November 2020 R105
DG-HT Series 20:1 turndown
Caution:

High fire gas offset should be set to zero. Use the appliance regulator to set.
Serial and Tag# Date
Model # Technician
Job Name Location
Sequence
1
2
3
4
5
6
Name High Fire
Near High
Fire
Low Fire
Near Low
Fire
Medium
Fire 1
Medium
Fire 2
% Fire 100 90 5 10 25 55
Man. Press.
Oxygen - O
2
CO
Air Offset
Air Vdc
Gas Offset
0
Gas Vdc
10
FACTORY CLOCKING
Clocking
Calculated
Clock Ratio 1.0 1.1 20.0 10.0 4.0 1.8
Setup Comments:
