Engcon MICROPROP DC2 User Manual

ALARMS
ENGLISH 30
Alarm headline Connector Short description Note
PWM X CM-X3.X SHORT CIRCUIT Short circuit in PWM output.
PWM X CM-X3.X OPEN CIRCUIT Open circuit in PWM output.
PWM X CM-X3.X SIGNAL ERROR
Wrong PWM signal from
PWM output.
ACT. SWITCH CM-X3.1 NOT ACTIVE
Activation switch for track or
wheel control is inactive.
JOYSTICK AI CALIBRATION INVALID Faulty calibration on analog
inputs.
JOYSTICK CM-X2.X (XAX) SHORT CIRCUIT Short circuit in analog input.
JOYSTICK CM-X2.X (XAX) OPEN CIRCUIT Open circuit in analog input.
JOYSTICK CM-X2.X (XAX) BELOW MIN / ABOVE
MIN
Faulty calibration on analog
inputs.
JOYSTICK CM-X2.X (XAX) START:OUTSIDE DB Analog input affected at
start up.
JOYSTICK CM-X2.X-X
(XAX)
SIGNAL ERROR Error at inverted signal.
JOYSTICK CM-X2.XX-XX
(XDX)
SHORT CIRCUIT Short circuit in digital input.
JOYSTICK CM-X2.XX-XX
(XDX)
OPEN CIRCUIT Open circuit in digital input.
JOYSTICK CM-X2.XX-XX
(XDX)
START: DI ACTIVE Digital input affected at start
up.
DI SUPPLY CM-X2.7 SHORT CIRCUIT Short circuit supply to digital
functions.
DI SUPPLY CM-X3 CM.X1 SHORT CIRCUIT Short circuit supply to digital
functions.
AI SUPPLY CM-X2.19 SHORT CIRCUIT Short circuit supply to
analog functions.
TOOL LOCK CM-X3.18-19
(TL)
SHORT CIRCUIT Short circuit tool lock switch.
TOOL LOCK CM-X3.18-19
(TL)
START: DI ACTIVE Tool lock switch active at
start up.
