ALARMS
ENGLISH 29
6.3. LIST OF ALARMS
In this table X is exchanged to corresponding letter or number shown in the cabin
module.
Alarm headline Connector Short description Note
SAFESTATE
1-8 - -
A safe state caused by
internal errors. Repeating
errors may mean the system
should be exchanged.
Contact support personnel.
SAFESTATE 9 - -
A safe state caused by
faulty pressure on CVP1.
Control the valve and
pressure sensor and the
connections.
SAFESTATE
10 - -
A safe state caused by
faulty pressure on CVP2.
Control the valve and
pressure sensor and the
connections.
SAFESTATE
11 - -
A safe state caused by
missing pressure on CVP1.
Control the valve and
pressure sensor and the
connections.
SAFESTATE
12 - -
A safe state caused by
missing pressure on CVP1.
Control the valve and
pressure sensor and the
connections.
CVP
MALFUNCTIO
N CM-X1.XX NO PRESSURE
No signal from pressure
switch CVPx. Control
pressure switch and wiring.
DOX CM-X1.X SHORT CIRCUIT Short circuit in digital output.
DOX CM-X1.X OPEN CIRCUIT Open circuit in digital output.
PWM X CM-X1.X SHORT CIRCUIT
Short circuit in analog
output.
PWM X CM-X1.X OPEN CIRCUIT
Open circuit in analog
output.
