TECHNICAL DATA

ENGLISH 34

CM :X1 Function CM :X2 Function CM :X3 Function

20 GND 20 GND 20 GND

21 Not connected 21 DI6 (LD1 NO) 21 GND

22 GND 22 DI7 (LD1 NC) 22 GND

23 +9-32VDC 15A 23 DI8 (LD2 NO) 23 USB 5V

24 DI11 (CVP1) 24 DI9 (LD2 NC) 24 USB - DATA

25 +12/24V 25 DI10 (LD3) 25 USB - DATA

26 DI12 (CVP2)

27 +12/24V

28 CAN-L

29 CAN-H

30 GND

31 VBAT2 (5A)

32 CAN-L

33 CAN-H

34 GND

35 VBAT1 (10A)
