LED Description
POWER
Lights up when powered ON. Blinks on
TEST/RESET
WLAN
Lights up in ORANGE when WLAN is
enabled. Blinks on traffic
LAN PORT ACTIVY
Blinks on traffic for specific LAN PORT
100 Mbps
Lights up when 100 Mbps data rate
enabled on that specific port
ITEM Description
Reset
Click this button to restart the system, or
Press this button and hold for 10 seconds
to restart the system.
WPS
Click this button to start WPS function.
DC IN
Power connector, connects to DC 12V
Power Adapter
LAN1 ~ 4
Local Area Network (LAN) ports 1 to 4
INTERNET
Wide Area Network(WAN) port
