EUB9801 – 300Mbps 802.11 a/b/g/n Dual Band Wireless N USB Adapter
14
† Profile: Enter a name for the profile; this does not need to be the same
as the SSID.
† SSID: Enter the SSID of the network or select one from the drop-down
list. The SSID is a unique name shared among all points in your wireless
network. The SSID must be identical for all points in the network, and is
case-sensitive.
† Network Type: Select Ad-hoc from the drop-down list.
† Preamble: Select Auto from the drop-down list, unless you are aware of
the preamble type (long or short) used in each station.
† Channel: Displays the channel number of the Access Point.
† TX Power: Select a transmit power from the drop-down list. If your
notebook is connected to external power then select 100% or auto, if
not, select one of the lower values for power saving.
† Click on the OK button to save the changes.
