Enhance Mobility MOJO Auto-Fold - Page 11

1
2
3
MOJO Disassembly
1 – Front Frame
Assembly 2 – Rear Axle
Group Release Lever
3 – Rear Axle Group
Pull the Rear Group
Release Lever toward
the back of the scooter
until the anti-tip wheels
touch the ground. At
the same time, lift on
the Front Frame
Assembly.
Continue to push
the front frame
assembly up and
forward until the
front frame
assembly is
separated from the
Rear Axle Group.
Done.
MOJO Assembly
1 – Rear Axle Group
Release Lever
2 – Rear Axle Group
3 – Front Frame
Assembly 4 – Front
Frame Stand
5 – Guide for Front Frame
Pull up on Rear Axle
Group Release Lever
until the anti-tip
wheels touch the
ground.
Lift the seat and
align the Front
Frame Stand onto
the Guide for the
Front Frame.
Pull the Front
Frame Assembly
down to the Rear
Axle Group.
Let the Front Frame
Assembly settle in
place and release
the Rear Axle Group
Release Lever.
1
3
2
5
4
Done！
