Enpower smart switch installation and operation
© 2020 Enphase Energy Inc. All rights reserved. 141-00046-01
50cm x 91.6cm x 24.6cm (19.7 in x 36 in x 9.7 in)
Ambient temperature range
-40º C to +50º C (-40º to 122º F)
Natural convection, plus heat shield
Enclosure environmental rating
Outdoor, NEMA type 3R, polycarbonate construction
To 2500 meters (8200 feet)
UL 1741, UL 1741 SA, UL1998, UL869A
D
, UL67
D
, UL508
D
, UL50E
D
CSA 22.2 No. 107.1, 47 CFR, Part 15, Class B, ICES 003, AC156.
A. Compatible with BRHDK125 Hold-Down Kit to comply with 2017 NEC 710.15E for back-fed circuit breakers.
B. The Enpower is rated 22 kAIC.
C. Not included. Installer must provide properly rated breaker per circuit breaker list above.
D. Sections from these standards were used during the safety evaluation and included in the UL 1741 listing.
