14
3. Failure Delection
10. Terms of Return
In the return of materials, user should send an open list related to damage or problem, malfunction of the material
to be returned or its operation in the different modification, with the instrument. If it is required to return the
material, used in the dangerous, corrosive or toxic fluid, in this case, used part should be cleaned very carefully.
Security of personnel should be ensured. All products to be returned should be sent to our company address, which
we have stated.
If you find an error, try to eliminate it by using this table or send the instrument to our service address for repair.
The instrument should be repaired only by authorized service!
4. Disassembly of Instrument
Instrument should be disassembled while feeding and pressure is not available!
5. Service
6. Recalibration
Calibration is not required during long period useful life of a level switch.
7. Repair '96Manufacturer Address
If irreparable breakdowns occur, the instrument should be sent to us for repair purpose. Before this, the instrument should be
cleaned carefully and packaged so as not to be broken. Furthermore, you should also add a detailed explanation which
describes the breakdown while instrument is sent. If your instrument contacts with harmful substances, decontamination
report should be also sent additionally. In the event that instrument does not have any decontamination report or our service
department has doubts about instrument, repair process will not start until an acceptable report is sent.
If the instrument contacts with hazardous substances, necessary measures should be taken for decontamination!
Service -Manufacturer Company Name and Address:
LONCA MAK. SAN. TÝC. A.Þ. Ferhatpaþa Mah. Gazipaþa Cad. No: 104A Ataþehir - ÝSTANBUL - TÜRKÝYE
Phone:+90 216 50 50 555 Fax:+90 216 515 45 84 E-Mail: lonca@ensim.com.tr Web: www.ensim.com.tr
8. Disposal
The instrument should be disposed according to 2002/96/EC and 2003/108/EC European Directives (waste electrical and
electronic instruments). Waste electrical and electronic equipment should not be mixed with domestic wastes!
If the instrument has contacted with harmful substances, special attention should be paid for its disposal!
9. Terms of Warranty
The instrument has warranty legally for 24 months after delivery date. Warranty demands are not accepted in case of
inappropriate operation, damage on the instrument or any modification on the instrument.
The instrument does not require maintenance. If it is desired, residue accumulated inside should be blown according to kind
of fluid and instrument can be cleaned with soft cleaning solutions. Measures should be taken during the disassembly.
Breakdown
Pedal was broken or bent
It does not contact or
it contacts continuously
Pedal does not come back,
it remains attached.
Housing was broken
Probable cause
- The product was not used in compatible with fluid flow.
- The product was not used in compatible with fluid pressure.
-Contact adjusting bar shifted.
- It was not connected with connection angle of 90 (vertical).
- Socket and/or cable may be damaged.
- Product was exposed to magnetic field in the ambient.
- It was applied to the higher values than application
current and/or voltage.
- Magnet may be damaged.
-Sedimentary and/or sticky fluid jammed the pedal.
- Pedal magnet was damaged as a result of taking a blow
after product fell.
-It was used in the higher heat than the application heating
value.
- The product was not selected in compatible with nature
of chemical flow.
- Tightening the screws more than adequate during the assembly.
- Product falling or taking a blow from outside.
-Inform the authorized service.
Failure detection\correction
-Check the flow range and use in compatible paller
with the flow.
-Select a model in compatible with the pressure.
-Adjust the sensitivity setting rod.
-Upright the connection position.
-Check for socket connections and cable damage.
-The factor which constitutes the magnetic
field should be removed or insulated.
-Inform the authorized service.
Pedal melted -Select a model in compatible with the temperature.
-Select a resistant model in compatible
with the chemical fluid.
-Use filter in the line to prevent dirtiness.
-Inform the authorized service.
Contact operates
unsteadily
- Exposing the product to the magnetic field in the ambient.
- Exposing the product to the vibration.
-The factor which constitutes the magnetic field
should be removed or insulated.
-Vibration should be prevented in order to affect
the product or it should be connected to a place
where vibration will not occur.
The factor which constitutes the magnetic field
should be removed or insulated.
