5
Installation For T-Type
Make sure the device is mounted on the pipe vertical.
Assemble the instrument manually.
Tighten the bolts as shown in the key figure. (G1/2"and G3/4" for max. 20 Nm )
2. Installation
2.1. General Notes
Installation of the instrument should be made only by authorized personnel.
Do not apply force to the instrument during the installation!
Do not use the level indicator with a greater pressure than recommended pressure.
Do not forget that instrument is precise, carry it carefully and prevent to be damaged.
It should be guaranteed that there are not any magnetic particles.
2.2. General Installation Stages
*Remove level indicator from the box carefully
*Check whether gasket is appropriate for fluid or not. If is not appropriate, contact with the producer.
*Then, apply below mentioned explanations according to structure of the design.
2.3. Special Notes
*Please ensure that there is no mechanical stress on the shaft following installation.
Such case will cause slipping in thecharacteristic curve.
*Flow switch should be placed in completely vertical position on the line.
*Allocate valve certainly in the process connection while instrument is used.
*Allocate blowdown valve under bottom flange for blowdown.
*If instrument is mounted outside and if there is any danger of lightning or
excessive pressure, take preventive measures by taking necessary measures.
*In the operating conditions, level indicator may be hot according
to situation of fluid, in this case, do not touch the indicator, otherwise your
skin is damaged.
2.4. Installation For Mechanical Connections
*Use appropriate O-Ring or gasket for tightness.
*Ensure that its surface is clean and smooth.
*Assemble the instrument manually.
*Attach float valve in such a manner that arrow will come up.
*Tighten the bolts as shown in the key figure. (Max. 20 Nm)
Installation For Plastic Type
Make sure the device is mounted on the pipe vertical.
Assemble the instrument manually.
Tighten the bolts as shown in the key figure. (Max. 10 Nm)
