MENU FEATURE OPTIONS STD. DEFAULT DESCRIPTION / COMMENTS
170 Remote Sensor 0-8 0 Select sensor if used. Contact PECO for information on the T8000 Series Indoor Remote Zone Sensor.
0 = No Remote Sensors
1 = Remote Indoor Sensor Only
2 = Not Used
3 = Not Used
4 = Not Used
5 = Not Used
6 = S3 Input with Aquastat Only
7 = S3 Input with Aquastat and S1 with Remote Indoor Sensor
8 = Not Used
171 Sensor Average
Remote & Local
0 – Local/Remote
1 – Average
Local/Remote
0 This feature allows both local and remote sensing. SM 170 must be set to either 01 or 07.
240 Number of Program
Periods
2; 4 events 4 2 = 2 events per day (Selections OCC1 and UnOcc1)
4 = 4 events per day (Selections Occ1-UnOcc1-Occ2- UnOcc2)
250 Clock Format 12 or 24 Hours 12 12 = 12-hour clock mode
24 = 24-hour clock mode
260 Temperature Format
(°F or °C)
0,1 1 0 = Celsius
1 = Fahrenheit
265 Single/Dual Setpoint 0,1 1 Determines if single user override setpoint is used, or if user sets heat and cool setpoints independently.
0 = Dual Setpoint (Heat and Cool)
1 = Single Override Setpoint (Single Setpoint with auto changeover algorithm)
290 Range Low 50-90 °F or
10-32°C
50°F
Choose the lowest selectable temperature setpoint value.
300 Range High 50-90 °F or
10-32°C
90°F
Choose the highest selectable temperature setpoint value.
310 Setback Low Off; 50-82°F 67°F Temperature setpoint thermostat will Heat to when in Setback mode (Off sets Heating to ~45F Setback).
0 = Off ; 50-82°F (11-27°C)
320 Setback High Off; 58-90°F 78°F Temperature setpoint thermostat will Cool to when in Setback mode. (Off sets Cooling to ~150F in
Setback).
0 = Off (disabled)
58-90°F (11-32°C)
325 Occupied Sensor
Operation
0-1 1 0 = Disabled
1 = Occupancy Operation ON
326 Occupied Timer
Duration
30 min; 1, 2 ,4, 6
8,16,20, 24 hrs
2 hrs Sets the time required to go into setback after last detection.
327 Setback Ramping 0, 1, 2 1 Determines how fast the control will setback.
0 = Economy (No delay)
1 = Comfort 1 (1 °F per hour)
2 = Comfort 2°(2 °F per hour)
328 Nighttime Lock On 0-1 0 Locks the thermostat to Occupied mode after 10:00pm. Thermostat resets at 08:00am.
NOTE: This feature requires the clock time to be set.
0 = Disabled
1 = ON
330 Zone Temp Offset +/-9°F or +/-
4.5°C
0°F
340 Keypad Lockout 0-3 0 Restricts access to certain features of device; Service Menu still available if keypad lockout is enabled.
0 = No key pad lockout (Default)
1 = Disables Schedule and System keys
2 = Disables Schedule, System, and Fan keys
3 = Disables all keys
341 Enable Pin Access 0,1 0 Applies a 3 digit access code to enter Service Menu 342
0 = Disable
1 = Enable
342 Set PIN 000-999 000 Choose a 3-digit PIN access code.
350 Fan Mode 1-3 3 1 = ON: Fan is always on, regardless of demand
2 = Auto: Fan is only on with heating or cooling demand
3 = ON or Auto: Occupant can choose either selection
360 System Mode 0-3 1 Allows ability to determine which system modes the occupant can select.
0 = OFF, Auto
1 = OFF, Heat, Cool, Auto
2 = OFF, Heat, Cool
3 = Heat, Cool, Auto
To Next Page
