Entrematic Ditec EL31R Quick Reference

IP2139 - 2014-09-30
Entrematic Group AB
Lodjursgatan 10
SE-261 44, Landskrona
Sweden
www.ditecentrematic.com
-
+
-
+
TC time setting
DISABLED!
MAX
1°
TC time setting
ENABLED!
2°
MIN=0 s
MAX
120 s
MIN=0 s
MAX
120 s
A
B
DIP1 = ON
DIP2 = ON
OPENING RADIO MODE
LEFT OPENING
DIP2 = OFF
RIGHT OPENING
DIP1 = OFF
STEP BY STEP RADIO MODE
15913 20 016841CNO 14 0
1112 0
VA VC TC R1
1
ON
23456
1
ON
23456 78
JR1
GOL4-GOL4C
Wait for 10 s
SIG
Push PRG
Led SIG comes on
Push CH
SIG
Led SIG flashes 3 times
1°
2°
PRG
SIG
JR1
DIP1=ON
DIP3=OFF
IMMEDIATE CLOSING
AFTER PASSAGE
1°
A
ON
OFF
123456
i
For different setting and further information consult the automation instruction manual, the control panel instruction
manual and radio instruction manual.
EL31R standard setting
Radio enabling
Automatic closing setting
Parking usage
