Ditec EL31R

IP1851EN

Installation Manual for control panel for 24V automations with built-in radio.

www.ditecentrematic.com

POWER

11IN

Limit switch

Accessories output

VC TC R1

AUX

SAFETY24V~

1591320 016841CNO

1112 0

14 0

PRG

COM

ENC

JR1

23456

23456 78

EL31R

SIG

-M

Power supply

Step-by-step

Safety stop

Safety reopening

Stop

Safety test

Flashing light

Gate open indicator light

Partial opening

GOL4

Transformer

Safety switch

24V=

Motor

BATK3

Main Page

Other manuals for Entrematic Ditec EL31R

Quick Reference2 pages

Questions and Answers

L
Lisa JonesAug 25, 2025
What to do if Entrematic Control Panel automation opens/closes briefly and then stops?
- N
  Nathan RobbinsAug 25, 2025
  If your Entrematic Control Panel automation opens or closes briefly and then stops, consider these potential causes: * **Encoder issues:** Check that the encoder is correctly connected. Clean the contacts by disconnecting and reconnecting the encoder plug. If necessary, replace the encoder. * **Motor lead problems:** Verify the motor leads are properly connected. * **Friction:** Manually inspect the automation to ensure it moves freely and check the R1 adjustment. * **Radio transmission interference:** If metal structures or reinforced concrete walls are impeding the radio transmission, install the antenna outside.
R
richardlyonsNov 8, 2025
Why Entrematic Ditec EL31R Control Panel automation does not open or close?
- A
  Ashley PhillipsNov 8, 2025
  There are several reasons why your Entrematic Control Panel automation might not be opening or closing: * **No power:** Ensure the control panel is receiving power. * **Short-circuited accessories:** Disconnect accessories from terminals 0-1, ensuring a 24V= voltage is present, then reconnect them one at a time to identify any faulty accessories. * **Blown line fuse:** Replace fuse F1. * **Open safety contacts:** Verify that the safety contacts are correctly closed (NC). * **Incorrectly connected safety contacts or malfunctioning self-controlled safety edge:** Inspect the connections to terminals 6-8 on the control panel and the connections to the self-controlled safety edge. * **Open SAFETY SWITCH release microswitch:** Make sure the hatch is properly closed and the microswit...
