1. General safety precautions
This installation manual is intended for qualified personnel only.
Installation, electrical connections and adjustments must be performed in accordance with Good Working Methods and in
compliance with the present standards.
Read the instructions carefully before installing the product. Bad installation could be dangerous.
The packaging materials (plastic, polystyrene, etc.) should not be discarded in the environment or left within reach of children,
as these are a potential source of danger.
Before installing the product, make sure it is in perfect condition.
Do not install the product in explosive areas and atmospheres: the presence of inammable gas or fumes represents a serious
safety hazard.
The safety devices (photocells, safety edges, emergency stops, etc.) must be installed taking into account: applicable laws and
directives, Good Working Methods, installation premises, system operating logic and the forces developed by the automation.
Before connecting the power supply, make sure the plate data correspond to that of the mains power supply. An omnipolar dis-
connection switch with minimum contact gaps of 3 mm must be included in the mains supply.
Check that upstream of the electrical installation there is an adequate residual current circuit breaker and a suitable overcurrent
cutout.
When requested, connect the automation to an effective earthing system that complies with current safety standards.
During installation, maintenance and repair operations, cut off the power supply before opening the cover to access the
electrical parts.
The electronic parts must be handled using earthed antistatic conductive arms. The manufacturer of the motorisation declines
all responsibility in the event of component parts being fitted that are not compatible with the safe and correct operation.
Use original spare parts only for repairs or replacements of products.
1.1 Installation precautions
Fix the control panel permanently. Pass the cables along the lower side of the container.
If they are accessible, block the cables with cable glands (not supplied). Keep the line and motor conductors separated from the
command conductors by at least 8mm in the terminal boards connection points (e.g. using straps).
Connect together the protection conductors (yellow/green) of the line and the motors, using the clamp supplied.
At the end of the installation, close the container.
