4 Call 1300 369 273 www.enware.com.au
components
ECE030 ECE060 ECE090 ECE240 ECE270
2
3
4
1
# Descripon
1 Base Frame Complete with Inspection Tag
2 Shower Arm & Rose
3 Pull Handle
4 Upper frame with ball valve
2
1
4
7
3
6
5
8
G
G
G
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1 794224
SUB ASS ECE TOP COMPLETE
1
2 794225
SUB ASS ECE PULL HANDLE
1
3 794553
SUB ASSY SHOWER ARM AND ROSE ECE SHOWER
1
4 891097
BOWL NEW STYLE 304 SS 0.9MM ECE
1
5 790486
SUB ASS FOOT PEDAL W/CABLE ECE SHOWER
1
6 794592
SUB ASS EYE/FACE WASH OUTLET ECE CAST
1
7 794250
SUB ASS ECE BOTTOM W/EYEWASH CTRL CAST
1
8 794591
SUB ASS PUSH HANDLE W/ STICKER ECE CAST
1
REVISION
REV.
DATE
ECN
DESCRIPTION
MODIFIED
BY
D
24/05/12
960 WAS 965
KN
E
20/09/13
INSTALL DETAILS ADDED
KN
F
4/12/14
2639
PULL HANDLE POSITION CHANGED
YK
G
30/03/15
4852
794250 WAS 794230; 794592 WAS 790481; 794591 ADDED; 995 WAS
960; 1015 WAS 990
YK
DRAWN
CHECKED
APPROVED
GENERAL NOTES:
- REMOVE ALL BURRS AND SHARP
EDGES UNLESS OTHERWISE STATED
- ALL THREADS TO BE CHAMFERED
- DIMENSIONS ARE IN mm's
- DO NOT SCALE OFF DIMENSIONS
TOLERANCE EXCEPT WHERE STATED:
NO DECIMAL POINT
+
-
2
ONE DECIMAL PLACE
+
-
1
ANGLES
+
-
1
ENWARE RESERVES THE RIGHT TO
AMMEND PRODUCT SPECIFICATIONS
AND DESIGNS WITHOUT NOTICE
FINISH:
SHEET: 2 OF 2
TITLE
S/S COMB D/SHWR E/F WSH
HND/FT
This drawing is the
property of Enware
Australia Pty Ltd and
may not be reproduced
in full or part without the
written consent of
Enware Australia.
9 Endeavour Rd,
Caringbah, NSW, 2229
Ph. 61-2-9525-9511
Fax. 61-2-9524-8421
LR
AC
KN
A
B
C
D
D
C
B
A
1
2
3
4
4
3
2
1
SIZE: A4
SCALE: 1:16
DRAWING
NUMBER:
Quality Endorsed
Company
AS/NZS ISO 9001
LIC No. 1213
Standards Australia
ECE270
# Descripon
1 Upper Frame with Ball Valve
2 Pull Handle
3 Shower Arm and Rose
4 New Style Bowl - 304 SS
5 Foot Pedal with Cable*
6A Eye Wash Outlet Assembly
6B Eye/Face Wash Outlet Assembly
7 Base Frame with Eyewash Control & Waste
8 Inspection Tag
* ECE090 and ECE270 only
2
1
4
6
3
5
7
F
F
F
ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1 794224
SUB ASS ECE TOP COMPLETE
1
2 794225
SUB ASS ECE PULL HANDLE
1
3 794553
SUB ASSY SHOWER ARM AND ROSE ECE SHOWER
1
4 891097
BOWL NEW STYLE 304 SS 0.9MM ECE
1
5 794589
SUB ASS EYEWASH OUTLET ECE CAST SHOWER
1
6 794250
SUB ASS ECE BOTTOM W/EYEWASH CTRL CAST
1
7 794591
SUB ASS PUSH HANDLE W/ STICKER ECE CAST
1
REVISION
REV.
DATE
ECN
DESCRIPTION
MODIFIED
BY
C
27/01/12
BOM CHANGED
KN
D
7/03/12
TOLERANCES ADDED
KN
E
4/12/14
2639
PULL HANDLE POSITION CHANGED
YK
F
31/03/15
4852
794250 WAS 794230; 794589 WAS 794368; 794591 ADDED; 995 WAS
960; 1005 WAS 985
YK
DRAWN
CHECKED
APPROVED
GENERAL NOTES:
- REMOVE ALL BURRS AND SHARP
EDGES UNLESS OTHERWISE STATED
- ALL THREADS TO BE CHAMFERED
- DIMENSIONS ARE IN mm's
- DO NOT SCALE OFF DIMENSIONS
TOLERANCE EXCEPT WHERE STATED:
NO DECIMAL POINT
+
-
2
ONE DECIMAL PLACE
+
-
1
ANGLES
+
-
1
ENWARE RESERVES THE RIGHT TO
AMMEND PRODUCT SPECIFICATIONS
AND DESIGNS WITHOUT NOTICE
FINISH:
SHEET: 2 OF 2
TITLE
SS DELUGE SHOWER HAND
OPERATED
This drawing is the
property of Enware
Australia Pty Ltd and
may not be reproduced
in full or part without the
written consent of
Enware Australia.
9 Endeavour Rd,
Caringbah, NSW, 2229
Ph. 61-2-9525-9511
Fax. 61-2-9524-8421
LR
AC
KN
A
B
C
D
D
C
B
A
1
2
3
4
4
3
2
1
SIZE: A4
SCALE: 1:15
DRAWING
NUMBER:
Quality Endorsed
Company
AS/NZS ISO 9001
LIC No. 1213
Standards Australia
ECE060
