3.01
EO Hub Connections
The EO Hub has the following
connections as shown in the
diagram below:
Install the EO Hub in a suitable
indoor location close to the
output of the electricity meter.
Physically mount it to the wall
using the mounting holes and
four appropriate screws (not
included).
An RJ45 connector cable is
provided to start your serial line
and should be connected to the
serial comms port of the EO
Hub.
Installation
instructions:
EO Hub.
EO Genius & EO Hub Installation Guide
© EO Charging 2021 11
3.0
Power
Genius
serial comms
CT clamps
Ethernet
Figure 1
