EO Mini Pro 2 Installation & User Guide
© EO Charging 2020
6.1
Important Installation
Information
Characteristics of power
supply input
Permanently connected to 230V AC supply.
Characteristics of power
supply output
Supplies 230V AC to the vehicle.
Normal environmental
conditions
Can be installed indoors or outdoors.
Access requirements Can be installed with no access restrictions.
Mounting method Stationary equipment intended for surface or post mounting.
Protection against electric
shock
Class I equipment.
Charging mode
Mode 3 charging equipment. Note - Adaptors and conversion adaptors sets are not allowed to be used with
the equipment. Cord extension sets are not allowed to be used.
Ventilation during supply of
energy
Does not support ventilation during charging.
Height of Installation The lowest point of the vehicle connector should be between 0.5m and 1.5m above ground level.
19
The installer must select
the Earthing and RCD
conguration in accordance
with local regulation & best
practice.
The EO Mini Pro 2 does not
include protection against loss
of Protective Earth Neutral
(PEN) conductor. Therefore the
unit must be installed with an
earth electrode or an alternative
fault protection solution.
Where the EO Mini Pro 2
includes DC leakage protection
a Type A RCD can be tted at
the supply. Otherwise a Type
B RCD or equivalent should be
used. EO recommend a 20A
supply rated supply circuit for
a 16A charging station and 40A
supply for on 32A charging
station.
