Eono PL2268-LK - Step 4: Adjustments; TV Tilt Angle Adjustment; Vertical Lock Option

8
Tilting angle adjustment (0°/-8°)
：
Pull TV to your desired angle then fasten 2 tilting bolts with
Allen key .
Option: To keep TV in vertical position, please use two pins to insert the holes on two
brackets respectively (as shown in below image).
0°
-8°
Tighten
Loosen
