Eono PL2268-LK - Step 2: Mount Wall Plate; Assemble Wall Plate Unit; Wood Stud Wall Installation

For wood stud installation, follow STEP 2A
For concrete installation, follow STEP 2B on PAGE 6
<16mm
(5/8")
24"(609.6mm)
/16"(406mm)
Min. Wood Stud Size:
nominal 2"(51mm)
actual 1 1/2"(38mm)
Min. Wood Stud Size:
nominal 4"(102mm)
actual 3 1/2"(89mm)
Wood Stud Installations
4
Parts and Hardware
Assemble Wall Plate
Wall plate(Left)
x1
Wall plate(Right)
x1
Wall plate unit
Lag Bolt M8x70mm
M8 Washer
x6 x6
x4
M5x8mm Bolt
Allen Key
x1
Concrete Wall Anchor 6pcs
CAUTION:
Do not use in drywall or wood
Fischer UX10x60 R
Mounting Template
