Monitor Terminal description
V Video Standby:0V, When monitor is On:appx 0.5V DC
A Audio Standby:appx 4.6VDC
When talking :appx 3.6VDC, When Door open:appx 12VDC
D Data Data signal between Monitors, Cameras and CPU4
+ - Power 13V DC power for Monitor / G Ground
Note:
● 0-50 meters, the cable size should be at least 0.5 mm²
● 50-100 meters, the cable size should be at least 0.75 mm²
● Max. working distance is 100 meters.
5. How to use:
5.1. To the right / To the left / Menu (OK) / Return
1 2 3 4
