M Series Hand Pallet Trucks
Parts list · Quick lift cylinder
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
WC02000121
WC02000723
WC02000060
WC02000036
WC02000061
WC02000059
WC02000058
WC02000035
WC02000045
WC02000046
WC02000038
WC02000071
WC02000037
WC02000122
WC02000064
WC02000063
WC02000123
WC01000046
WC02000049
WE06000005
WE03000003
WE04000003
WC02000126
WC02000127
WC02000132
WC02000129
WC02000131
WC02000128
WC02000130
WC02000124
WC02000125
WE06000011
Valve bodyseaming part(AC-85), quick lift pump, galvanized
Valve bodyseaming part(AC-75), with quick lift, galvanized
GB982, Seal washer 10
Bolt
Seal ring UHS35
GB3452.1, O-ringφ34.5×3.55
Dusty seal ringDH35
Piston rod
Safety valve
Pressure spring
Pressure adjusting screw
GB3452.1, O-ringφ11.2×2.65
Screw
Quick lift pump body
Seal ring UHS18
Dusty seal ringDH18
Quick lift pump pistion
One valve assembly
Unloading plate, galvanized
GB879.1 Pin 8×50, black
GB73 Screw M8×20, galvanized
GB6172.1 Hex nut M8, galvanized
Copper gasket
Quick lift blind nut
GB3452.1, O-ringφ9.0×1.8
GB308, Steel ball S5
GB3452.1, O-ringφ27×3
Centre
Spring
Spring cover
Pressure spring
GB119.1 Pin 4×28, galvanized
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Qty.
NO. Parts number
Description
22
