6
E
3.2
.1
Tyre size, driving
wheels(diameter×width)
mm Ф230x75 Ф230x75
3.3.1 Tyre size, loading
wheels(diameter×width)
mm Ф85x70 / Ф83x115 Ф85x70 /
Ф83x115
3.4 Tyre size, caster
wheels(diameter×width)
mm Ф130x55 Ф130x55
3.5 Wheels, number driving,
caster/loading (x=drive
wheels)
mm 1x,2/4(1x,2/2) 1x,2/4(1x,2/2)
3.6 Track width, front,driving side b10 mm 510 510
3.7 Track width,rear,loading side b11 mm 370/495 370/495
Dimensions
4.4 Lift height h3 mm 120 120
4.9 Height drawbar in driving
position min./max.
h14 mm 1075 / 1288 1075/ 1288
4.15 Lowered height h13 mm 85 85
4.19 Overall length l1 mm 1954 1954
4.20 Length to face of forks l2 mm 824 824
4.21 Overall width b1/ b2 mm 734 734
4.22 Fork dimensions s/ e/ l mm 55 x 190 x 1150 55 x190 x1150
4.25 Distance between fork-arms b5 mm 560/685 560/685
4.32 Ground clearance, center of
wheelbase
m2 mm 30 30
4.34.1 Aisle width for pallets 1000 ×
1200 crossways
Ast mm 2590 2590
4.34.2 Aisle width for pallets 800 ×
1200 lengthways
Ast mm 2447 2447
4.35 Turning radius Wa mm 1790 1790
Performance data
5.1 Travel speed, laden/ unladen km/ h km/h 5.5 / 6 5.5 / 6
5.2 Lifting speed, laden/ unladen m/ s 0.050 / 0.054 0.050 / 0.054
