E+E Elektronik EE820 - Technical Data

User Manual EE820
CO
2
Sensor for Demanding Applications | 11
8 Technical Data
Measurands
CO
2
Measurement principle Dual wavelength non-dispersive infrared technology (NDIR)
Measuring range 0...2 000 / 5 000 / 10 000ppm
Accuracy
@25°C(77°F)and1 013mbar(14.7psi)
0...2 000 ppm
0...5 000 ppm
0...10 000 ppm
< ±(50 ppm + 2 % of measured value)
< ±(50 ppm + 3 % of measured value)
< ±(100 ppm + 5 % of measured value)
Temperature dependency
in the range of -20...45 °C (-4...113 °F)
±(1 + CO
2
concentration[ppm]/1 000)ppm/°C
Response time t
63
, typ. 300 s
Sampling interval, approx. 15 s
Outputs
Analogue
CO
2
0...2 000 / 0...5 000 / 0...10 000 ppm 0 - 10 V -1mA < I
L
< 1 mA I
L
= load current
4 - 20 mA R
L
≤500Ω R
L
= load resistance
General
Power supply class III
USA & Canada: Class 2 supply necessary,
max. voltage 30 V DC
24 V DC ±20 % 15 - 35 V DC
Current consumption, typ. 15 mA + output current
Peak current, max.
@ analogue output
350 mA for 0.3 s
Warm-up time
1)
< 5 min
Electrical connection Screw terminals max. 2.5 mm
2
or M12 plug
Working conditions -20...+60 °C (-4...+140 °F)
0...100 %RH, non-condensing
Storage conditions -20...+60 °C (-4...+140 °F)
0...95 %RH, non-condensing
Enclosure
Material
Protection rating
Polycarbonate (PC), UL94 V-0 approved
IP54
Electromagnetic compatibility EN 61326-1 EN 61326-2-3 Industrial environment
FCC Part15 Class B ICES-003 Class B
Conformity
1) For performance according to specification.
