Step 1: Wiring
The recommended connection order has been provided as Figure3-2
indicated. Be sure the negative and positive polarity connection is
correct and all terminals are tightened.
Figure 3-2 System wiring review
Step 2: Confirm power on
When battery power is applied and the controller starts up, the battery
LED indicators will be on. If the controller doesn't start up, or the
battery LED error exists, please refer to section 5 for troubleshooting.
