3.2 Wiring
NOTE: A recommended connection order has
been provided for maximum safety during
installation.
NOTE: The controller is a common positive
ground controller.
CAUTION: Don’t connect the loads with surge
power exceeding the ratings of the controller.
CAUTION: For mobile applications, be sure to
secure all wiring. Unsecured cables create loose
and resistive connections which may lead to
excessive heating and/or fire.
WARNING: Risk of explosion or fire! Never
short circuit battery positive (+) and negative (-)
or cables.
WARNING: Risk of electric shock! Exercise
caution when handling solar wiring. The solar
module(s) high voltage output can cause severe
shock or injury. Be careful operation when
installing solar wiring.
