Epsolar LS0512 - Page 21

17
Charging status LED indicator Table 4-1
Indicator
Charging Status
On Solid
Charging
Fast Flashing
Battery over voltage
Battery status indicator
LED1 SLOWLY FLASHING when battery under voltage
LED1 FAST FLASHING when battery over discharged
Please see the instruction of battery voltage indicating in the table 4-2.
Please refer to section 5 for troubleshooting.
Battery LED indicator Table 4-2
LED1
LED 2
LED 3
LED 4
Battery Status
SLOWLY
FLASHING
×
×
×
Under voltage
FAST
FLASHING
×
×
×
Over discharged
Battery LED indicator status during voltage is up
○
○
×
×
＞12.8V
○
○
○
×
＞13.4V
○
○
○
○
＞14.1V
Battery LED indicator status during voltage is down
○
○
○
×
＜13.4V
○
○
×
×
＜12.8V
