CameraOrientation Property
CameraOrientation Property
Applies To
Vision Calibration
Description
Sets / returns the CameraOrientation type for the specified calibration.
Usage
VGet Calibration.CameraOrientation, var
VSet Calibration.CameraOrientation, value
Calibration Name of a calibration or string variable containing a calibration name.
var Integer variable that will contain the value of the property.
value Integer expression for the new value of the property.
Values
1 - Standalone
2 - Fixed Downward
3 - Fixed Upward
4 - Mobile on J2
5 - Mobile on J4
6 - Mobile on J5
7 - Mobile on J6
Default: 1
Remarks
The CameraOrientation property must be set before teaching calibration points.
See Also
Camera Property, CameraGain Property, Sequence Tab, Vision Sequences
Vision Guide 5.0 Reference (Ver.5.3) Rev.1 21
