• 301 to 600 dpi: 53 inches (1346 mm) or less
Parent topic: Loading Originals
Loading Booklets (DS-C490)
You can load small booklets into the scanner. Make sure the booklet meets the specifications before
loading it.
Note: You can scan A5-sized booklets that are less than 0.20 inches (5 mm) thick when closed.
1. Make sure the scanner position light is on.
Note: If the scanner position light is off, pull the position selector to the right and tilt the scanner
backwards.
