Epson EB-450W Installation Guide

8
2. Specifications
Wall plate
Setting plate adjustment range
Item Specification Remark Reference Page
Setting plate mass Approx. 6.3 kg
(13.89 lb.)
Wall plate (2.2 kg [4.85 lb.])
Covers and cap (0.47 kg [1.04 lb.])
Forward/backward slide
adjustment range
0 to 300 mm
(11.81 in.)
Refer to the figure
below
Vertical slide adjustment range 4
°
Minimum: 28 mm (1.10 in.)
Maximum: 42.5 mm (1.67 in.)
s p. 20
Vertical tilt adjustment range ± 5
°
Fine adjustments possible with adjustment dial
s p. 18
Horizontal rotation adjustment
range
± 5
°
Fine adjustments possible with adjustment dial
s p. 19
Horizontal roll adjustment range ± 3
°
Fine adjustments possible with adjustment dial
s p. 19
Horizontal slide adjustment range ± 45 mm
(1.77 in.)
Refer to the figure
below
[Unit: mm (in.)]
Forward/backward slide adjustment range:
0 to 300 mm (11.81 in.)
Horizontal slide adjustment range:
± 45 mm (1.77 in.)

Epson EB-450W Specifications

General

Projection technology	LCD
Contrast ratio (typical)	2000:1
Projector native resolution	WXGA (1280x800)
Aspect ratio	16:10
RS-232 ports	1
Dimensions (WxDxH)	369 x 481 x 115 mm
Lamp type	UHE
Lamp power	230 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3500 h
Focal length range	0 - 4.68 mm
RMS rated power	10 W
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	2
Power consumption (standby)	1 W
Operating temperature (T-T)	0 - 35 °C

Weight and Dimensions

Weight	5700 g
