21
English
7. Attaching the Covers
A Attach the wall plate cover and end cap
(1) Secure the wall plate cover with the two M4 x 12 mm hexagon socket head cap bolts (A).
(2) Place the end cap with the concave portion facing up (
B).
B Attach the cable cover to the projector
Attach the cable cover and tighten the two screws to secure the cable cover.
q
Depending on how the cables are wired, you may need to cut out parts of the wall
plate cover to allow the cables to be passed through it.
End cap
Wall plate cover
M4 x 12 mm
hexagon socket head
cap bolts (2)
Only a specialist should remove or reinstall the projector, including for maintenance and
repairs. Refer to the User’s Guide of your projector for instructions on maintenance and repairs.
