Epson EB-450W User Manual

Connecting with a USB cable and projecting (USB Display)
By simply connecting the supplied USB cable to a computer, you can
project images from the computer's screen.
s
Quick Start Guide , p.23
Projecting a computer screen with the optional Quick Wireless
Connection USB Key
Using the optional Quick Wireless Connection USB Key, you can quickly
connect a computer to the projector for projection.
With the Quick Wireless Connection USB Key, you can connect to a
projector on a network even if EasyMP Network Projection is not installed.
For example, you can connect under the following environments.
• Connect in Quick Connection Mode using the optional Wireless LAN
unit.
• Connect to the network via an access point.
• Connect to the network via a wired LAN connection.
s p.117
q
• This projector is not compatible with the Network Projector
function which is a standard feature in Windows Vista and
Windows 7.
• Limitations when projecting from Windows Media Center
When Windows Media Center is in full-screen mode, images cannot
be projected. Switch to the window display mode to project the
images.
Projector Features
9

Epson EB-450W Specifications

General

Projection technology	LCD
Contrast ratio (typical)	2000:1
Projector native resolution	WXGA (1280x800)
Aspect ratio	16:10
RS-232 ports	1
Dimensions (WxDxH)	369 x 481 x 115 mm
Lamp type	UHE
Lamp power	230 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3500 h
Focal length range	0 - 4.68 mm
RMS rated power	10 W
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	2
Power consumption (standby)	1 W
Operating temperature (T-T)	0 - 35 °C

Weight and Dimensions

Weight	5700 g
