Epson EB-450W User Manual

You can save the image that is currently being projected as a User Pattern.
q
When a User Pattern is saved, the previous User Pattern is erased.
Procedure
A Project the image you want to use as the User Pattern, and
then press the [Menu] button.
Using Remote Control Using Control panel
B Select Pattern from the Settings Menu in the Configuration
Menu.
s "Using the Configuration Menu" p.73
C Select User Pattern.
q
If User Pattern is selected when one of the Keystone, E-Zoom, Aspect,
Progressive, and Zoom Adjustment functions is being used, the
function currently being used is cancelled temporarily.
D When "Do you want to use the currently projected image as
the User Pattern?" is displayed, select "Yes".
E
When you press the [Enter] button, the message "Do you save
this image as the User Pattern?" is displayed. Then, select
"Yes".
The image is saved. After the image has been saved, the message "The
User Pattern setting is complete." is displayed.
q
• Once a User Pattern has been saved, User Pattern cannot be
returned to the factory default.
• Saving the User Pattern may take approximately 15 seconds. Do not
use the projector or any connected equipment while it is saving,
otherwise malfunctions may occur.
Saving User Pattern
71

Epson EB-450W Specifications

General

Projection technology	LCD
Contrast ratio (typical)	2000:1
Projector native resolution	WXGA (1280x800)
Aspect ratio	16:10
RS-232 ports	1
Dimensions (WxDxH)	369 x 481 x 115 mm
Lamp type	UHE
Lamp power	230 W
Light source type	Lamp
Service life of light source	2500 h
Service life of light source (economic mode)	3500 h
Focal length range	0 - 4.68 mm
RMS rated power	10 W
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	2
Power consumption (standby)	1 W
Operating temperature (T-T)	0 - 35 °C

Weight and Dimensions

Weight	5700 g
