Epson EB-570 Installation Guide

Contents
5
Using the Product Safely
Safety Instructions .................... 1
Safety indications .......................1
Explanation of Symbols ................... 1
Safety Precautions for Installation ............1
About This Installation Guide...............3
Choosing an Installation Location ...... 4
Projector installation location ............... 4
Installation Guide
Installation Work Flow ................ 6
Package Contents . . ................... 7
Setting plate ........................... 7
Specifications . . . . . ................... 8
Setting plate ........................... 8
Wall plate ........................... 8
Vertical slide adjustment range ............ 9
Horizontal slide adjustment range .......... 9
Forward/backward slide adjustment range
...................................9
Projection Distance Table ............ 11
Figures of Installation Dimensions ........... 11
Interactive whiteboard list (EB-585W/
580/575W/570 only) ................... 12
When Projected Image is Smaller than 75 Inches
.................................... 13
EB-585Wi/585W/575Wi/575W (16:10
projected image) .....................14
EB-585Wi/585W/575Wi/575W (16:9
projected image) .....................14
EB-585Wi/585W/575Wi/575W (4:3
projected image) .....................15
EB-580/570 (4:3 projected image).........17
EB-580/570 (16:9 projected image)........17
EB-580/570 (16:10 projected image).......18
When Projected Image is Larger than 75 Inches
.................................... 19
EB-585Wi/585W/575Wi/575W (16:10
projected image) .....................20
EB-585Wi/585W/575Wi/575W (16:9
projected image) .....................21
EB-585Wi/585W/575Wi/575W (4:3
projected image) .....................22
EB-580/570 (4:3 projected image).........23
EB-580/570 (16:9 projected image)........23
EB-580/570 (16:10 projected image).......24
Installing the Setting Plate ........... 26
Connecting Devices ..................... 26
Necessary cables.....................26
Installation Procedure ................... 27
Disassemble the parts................. 27
Assemble the parts ...................27
Install the wall plate on the wall..........29
Determine the projection distance, and then
pass the cables through the setting plate . . . . 31
Attaching the setting plate to the wall plate
.................................. 33
Securing the projector to the setting plate
.................................. 35
Adjusting the Projected Image.............37
Adjusting the Projection Position.........37
Fine-tuning the Focus.................42
Calibrating the Pen (EB-585Wi/575Wi only)
.................................. 44
Attaching the Covers .................... 48
Appendix
Batch Setup Function ................ 50
Setup Using a USB flash drive.............. 50
Saving settings to the USB flash drive......50
Reflecting saved settings to other projectors
.................................. 51
Setup by Connecting the Computer and
Projector with a USB Cable................ 52
Saving settings to a computer ............ 53
Reflecting saved settings to other projectors
.................................. 53
When Setup Fails ....................... 55
Using the Interactive Function when
Multiple Projectors are Installed . . . . . . 56
Attaching a Security Cable ............ 57
General Notice ...................... 58

Epson EB-570 Specifications

General

Matrix size	0.55 \
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Contrast ratio (typical)	10000:1
Screen size compatibility	56 - 93 \
Projection distance (tele)	0 - 0.6 m
Projection distance (wide)	0 - 0.4 m
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	1500 ANSI lumens
Focus	Manual
Throw ratio	0.3:1
Digital zoom	1.35 x
Focal length range	0 - 3.71 mm
Lamp power	215 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Video processing	10 bit
Analog signal format system	-
Supported graphics resolutions	1024 x 768 (XGA)
Microphone in	Yes
Audio (L/R) in	0
Composite video in	1
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	35 dB
Country of origin	Philippines
2D/3D frequency image	50 - 85 Hz
Noise level (economic mode)	28 dB
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
RMS rated power	16 W
Placement	Desktop
Product type	Ultra short throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.33 W
Power consumption (typical)	318 W
Power consumption (PowerSave)	230 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	USB
Bundled software	EasyMP Monitor, EasyMP Multi PC Projection, EasyMP Network Projection
Pallet width	800 mm
Pallet height	2040 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	375 mm
Width	367 mm
Height	155 mm
Weight	5300 g
Package depth	810 mm
Package width	520 mm
Package height	320 mm
Package weight	18520 g
