a
If Password Protection is already activated, you must enter
the password.
If the password is entered correctly, the Password Protection
setting menu is displayed.
s "Entering the Password" p.111
When the password is set, stick the supplied password protect
sticker in a visible position on the projector as a further theft
deterrent.
b
Select the type of Password Protect you want to set, and then
press the [Enter] button.
c
Select On, and then press the [Enter] button.
Press the [Esc] button, the screen displayed in step 2 is displayed
again.
d
Set the password.
(1) Select Password, and then press the [Enter] button.
(2) When the message "Change the password?" is displayed, select Yes and
then press the [Enter] button. The default password is set to "0000".
Change this to your own desired Password. If you select No, the screen
displayed in step 2 is displayed again.
(3) While holding down the [Num] button, enter a four digit number using
the numeric buttons. The number entered is displayed as "* * * *". When
you enter the fourth digit, the confirmation screen is displayed.
Remote control
(4) Re-enter the password.
The message "Password accepted." is displayed.
If you enter the password incorrectly, a message is displayed prompting
you to re-enter the password.
Entering the Password
When the password entry screen is displayed, enter the password using the
remote control.
While holding down the [Num] button, enter the password by pressing the
numeric buttons.
When you enter the correct password, Password Protect is temporarily
released.
Security Functions
111
