Epson EB-570 User Manual

Notations Used in This Guide ........................ 2
Introduction
Projector Features .......................................... 8
Interactive Features (Easy Interactive Function) (EB-595Wi/EB-585Wi/EB-575Wi only)
...........................................................8
Enabling Projection from a Short Distance.............................8
Connecting to a Network and Projecting Images from the Computer's Screen . . . . . 8
Enhanced Security Functions......................................9
Enlarge and Project Your Files with the Document Camera..................9
Part Names and Functions .................................. 11
Front/Side ..................................................11
Top/Side...................................................12
Interface...................................................13
Base ...................................................... 14
Attaching the Feet (only Models with Feet Supplied)...................15
Control Panel................................................16
Remote Control ...............................................17
Replacing the Remote Control Batteries............................19
Remote Control Operating Range................................ 20
Interactive Pen (EB-595Wi/EB-585Wi/EB-575Wi only) . . . . . . ...............20
Replacing the Battery for the Interactive Pen .........................21
Replacing the Tip of the Interactive Pen............................22
Pen Tray (EB-595Wi/EB-585Wi/EB-575Wi only) .......................... 23
Touch Unit (EB-595Wi only) .......................................23
Front ....................................................23
Rear .....................................................24
Preparing the Projector
Installing the Projector ..................................... 26
Installation Methods........................................... 26
When Using the Interactive Features (EB-595Wi/EB-585Wi/EB-575Wi only) . ....27
Setting up the Touch Unit (EB-595Wi only)..........................28
Connecting Equipment ..................................... 29
Connecting a Computer......................................... 29
Connecting a Smartphone or Tablet Device............................31
Connecting Image Sources.......................................32
Connecting USB Devices .........................................35
Connecting a Microphone.......................................37
Connecting External Equipment...................................38
Connecting a LAN Cable......................................... 40
Installing the Optional Wireless LAN Unit.............................41
Connecting Multiple Projectors (EB-595Wi/EB-585Wi/EB-575Wi only) . . . . . . . . . . 42
Basic Usage
Projecting Images ......................................... 45
Getting Ready to Project .........................................45
Automatically Detect Input Signals and Change the Projected Image (Source Search)
.......................................................... 46
Switching to the Target Image Using the Remote Control..................47
Projecting with USB Display......................................48
System Requirements........................................48
Connecting for the First Time...................................49
Uninstalling...............................................50
Adjusting Projected Images ................................ 52
Correcting Keystone Distortion.................................... 52
H/V-Keystone..............................................52
Quick Corner ...............................................53
Adjusting the Image Size........................................55
Adjusting the Position of the Image (Image Shift)........................ 55
Adjusting the Vertical Position of the Image (Models Supplied with the Feet only)
.......................................................... 56
Raising the Height of the Image ..................................56
Lowering the Height of the Image................................56
Adjusting the Horizontal Position of the Image (Models Supplied with the Feet only)
.......................................................... 56
Correcting the Focus...........................................57
Contents
3
http://www.pureglare.com.au

Epson EB-570 Specifications

General

Matrix size	0.55 \
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Contrast ratio (typical)	10000:1
Screen size compatibility	56 - 93 \
Projection distance (tele)	0 - 0.6 m
Projection distance (wide)	0 - 0.4 m
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	1500 ANSI lumens
Focus	Manual
Throw ratio	0.3:1
Digital zoom	1.35 x
Focal length range	0 - 3.71 mm
Lamp power	215 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Video processing	10 bit
Analog signal format system	-
Supported graphics resolutions	1024 x 768 (XGA)
Microphone in	Yes
Audio (L/R) in	0
Composite video in	1
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	35 dB
Country of origin	Philippines
2D/3D frequency image	50 - 85 Hz
Noise level (economic mode)	28 dB
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
RMS rated power	16 W
Placement	Desktop
Product type	Ultra short throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.33 W
Power consumption (typical)	318 W
Power consumption (PowerSave)	230 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	USB
Bundled software	EasyMP Monitor, EasyMP Multi PC Projection, EasyMP Network Projection
Pallet width	800 mm
Pallet height	2040 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	375 mm
Width	367 mm
Height	155 mm
Weight	5300 g
Package depth	810 mm
Package width	520 mm
Package height	320 mm
Package weight	18520 g
