Epson EB-570 User Manual

Adjusting the Volume..........................................59
Selecting the Projection Quality (Selecting Color Mode) ...................60
Setting Auto Iris..............................................60
Changing the Aspect Ratio of the Projected Image.......................61
Changing Methods.......................................... 61
Changing the Aspect Mode (EB-595Wi/EB-585Wi/EB-585W/EB-575Wi/EB-575W
only)....................................................61
Changing the Aspect Mode (EB-580/EB-570 only) ......................63
Using the Interactive Features
(EB-595Wi/EB-585Wi/EB-575Wi only)
Interactive Feature Modes .................................. 65
Drawing on a Projected Image (Annotation Mode).......................66
Using the Projected Screen as a Whiteboard (Whiteboard Mode).............67
Controlling Computer Features from a Projected Screen (Computer Interactive
Mode).....................................................68
Computer Interactive Mode System Requirements .....................68
Using Computer Interactive Mode................................68
Easy Interactive Driver System Requirements (OS X only) ................. 71
Installing Easy Interactive Driver on OS X ............................72
Using the Interactive Pens .................................. 73
Pen Calibration ............................................... 74
Calibrating Automatically ......................................75
Calibrating Manually .........................................76
Adjusting the Pen Operation Area..................................78
Using Your Finger for Interactive Touch Operations (EB-595Wi
only) ..................................................... 80
Safety Instructions for Interactive Touch Operations......................80
Laser Warning Labels......................................... 80
Using Interactive Touch Operations with Your Finger .....................81
Calibrating for Touch Operations with Your Finger .......................82
Interacting with the Screen ................................. 86
Switching the Interactive Mode .................................... 86
Annotation Mode and Whiteboard Mode Toolbars .......................87
Selecting Line Width and Color.................................. 88
Selecting Whiteboard Templates.................................89
Projector Control Toolbar ........................................89
Selecting Network Device Display from the Projector Control Toolbar........90
Using the Interactive Features over a Network ............... 92
Precautions When Connecting to a Projector on a Different Subnet...........92
Windows Pen Input and Ink Tools ........................... 94
Enabling Windows Pen Input and Ink Features..........................94
Using Windows Pen Input and Ink Features............................95
Useful Functions
Projection Functions ....................................... 97
Projecting Images Stored on a USB Storage Device (PC Free)................97
Specifications for Files that Can Be Projected Using PC Free...............97
PC Free Examples........................................... 97
PC Free Operating Methods....................................98
Projecting the Selected Images or Movies ...........................99
Projecting Image Files in a Folder in Sequence (Slideshow).............. 100
Image File Display Settings and Slideshow Operation Settings ............ 101
Hiding the Image and Sound Temporarily (A/V Mute) .................... 102
Freezing the Image (Freeze)..................................... 102
Pointer Function (Pointer) .......................................103
Enlarging Part of the Image (E-Zoom) ............................... 103
Using the Remote Control to Operate the Mouse Pointer (Wireless Mouse) ...... 104
Saving a User's Logo ...........................................106
Saving User Pattern ........................................... 108
Security Functions ........................................ 110
Managing Users (Password Protection) .............................. 110
Kinds of Password Protection .................................. 110
Setting Password Protection ................................... 110
Entering the Password....................................... 111
Restricting Operation (Control Panel Lock) ........................... 112
Contents
4
http://www.pureglare.com.au

Epson EB-570 Specifications

General

Matrix size	0.55 \
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Contrast ratio (typical)	10000:1
Screen size compatibility	56 - 93 \
Projection distance (tele)	0 - 0.6 m
Projection distance (wide)	0 - 0.4 m
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	1500 ANSI lumens
Focus	Manual
Throw ratio	0.3:1
Digital zoom	1.35 x
Focal length range	0 - 3.71 mm
Lamp power	215 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	10000 h
Full HD	No
Video processing	10 bit
Analog signal format system	-
Supported graphics resolutions	1024 x 768 (XGA)
Microphone in	Yes
Audio (L/R) in	0
Composite video in	1
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Ethernet LAN data rates	10, 100 Mbit/s
Noise level	35 dB
Country of origin	Philippines
2D/3D frequency image	50 - 85 Hz
Noise level (economic mode)	28 dB
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
RMS rated power	16 W
Placement	Desktop
Product type	Ultra short throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.33 W
Power consumption (typical)	318 W
Power consumption (PowerSave)	230 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	USB
Bundled software	EasyMP Monitor, EasyMP Multi PC Projection, EasyMP Network Projection
Pallet width	800 mm
Pallet height	2040 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	375 mm
Width	367 mm
Height	155 mm
Weight	5300 g
Package depth	810 mm
Package width	520 mm
Package height	320 mm
Package weight	18520 g
