Epson EB-735F User Guide Supplement

Details of User Operation Change (Version 2.00)
12
Refer to these sections for details on changes to user operations.
gg Related Links
• "Using the Wireless Presentation System to Connect Windows/Mac
Computers" p.12
Using the Wireless Presentation System to Connect
Windows/Mac Computers
You can use the optional wireless presentation system to quickly connect the
projector to computers wirelessly and project your image. Your wireless
presentation system (ELPWP10) includes two wireless transmitters
(ELPWT01) and one wireless LAN module (ELPAP11).
See the Epson Wireless Presentation System User's Guide for details.
gg Related Links
• "Setting Up the Wireless Presentation System for the First Time" p.12
• "Projecting with the Wireless Presentation System" p.13
Setting Up the Wireless Presentation System for the First Time
The first time you start using the wireless presentation system, you need to
make preparations such as pairing the wireless transmitters with the projector.
a
• Select network settings for the projector before pairing.
• You need to pair the wireless transmitters again when you change
Projector Name or Passphrase in the Network Settings menu.
• You can also pair the wireless transmitters from your computer using
the Epson Wireless Transmitter Settings software. See the Epson
Wireless Transmitter Settings Operation Guide for details.
• You can download the necessary software and manuals from the
following Web site:
epson.sn
a
Turn on the projector.
b
Connect the wireless transmitter to the projector's USB-A port.
The network information is written and a completion message is
displayed. It may take some time to finish pairing.
Caution
Do not disconnect the power cord or the wireless transmitter from the
projector while the network information is being written. If the power cord
or wireless transmitter is disconnected, the projector may not start
correctly. Make sure the completion message is displayed before
disconnecting the wireless transmitter.
c
Connect the other wireless transmitters if you want to continue pairing.
d
Select Yes to set Connection Guide Display to On if necessary.

Epson EB-735F Specifications

General

Matrix size	0.61 \
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	- m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	65 - 120 \
Projector native resolution	1080p (1920x1080)
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	2500 ANSI lumens
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Focus	Manual
Throw ratio	0.26 - 0.36:1
Zoom capability	Yes
Fixed focal length	3.7 mm
3D	No
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
HDMI connector type	Full-size
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 2.0 Type-B ports quantity	1
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Noise level	36 dB
Country of origin	China
Noise level (economic mode)	26 dB
Cables included	AC
Bundled software	EasyMP Multi PC Projection, Epson Projektor Management
Storage temperature (T-T)	-10 - 60 °C
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	255 W
Power consumption (economy mode)	197 W
Placement	Ceiling, Wall
Product type	Ultra short throw projector
Product color	White
Cable lock slot type	Kensington
RMS rated power	16 W
Supported network protocols	HTTPS, IPv4, IPv6, SNMP, ESC/VP.net, PJLink
Sustainability certificates	TCO
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	12 pc(s)
Quantity per pallet (UK)	24 pc(s)
Harmonized System (HS) code	85286200
Software support	via: AMX, Crestron (Network), Extron, Crestron (RS-232C only), Crestron Integrated Partner, Crestron RoomView, Extron IP Link, Extron XTP, AMX Device Discovery, Control4 Simple Device Discovery Protocol

Weight and Dimensions

Depth	395 mm
Width	356 mm
Height	133 mm
Weight	5700 g
Package depth	475 mm
Package width	442 mm
Package height	315 mm
Package weight	8209 g
