Epson EB-915W User Manual

Notations Used in This Guide ........................ 2
Introduction
Projector Features .......................................... 7
List of Functions by Model........................................7
Quick and Easy Set up, Projection, and Storage..........................8
Easy writing on a whiteboard or blackboard using the pattern function........ 8
Connecting with a USB cable and projecting (USB Display)................8
Detecting projector movements and automatically correcting image distortion
.........................................................8
Useful Functions for Projecting Images................................8
Increasing projection content in wide (WXGA) screen (EB-915W/EB-910W/EB-96W
only) .....................................................8
Connecting to a network and projecting images from the computer's screen
.........................................................8
Easy connection to a computer with Quick Wireless .....................9
Making the most of the remote control.............................9
Enlarge and project your files with the Document Camera .................9
Enhanced security functions ..................................... 9
Part Names and Functions .................................. 10
Front/Top ...................................................10
Rear .......................................................11
Base ......................................................12
Control Panel................................................13
Remote Control...............................................14
Replacing the remote control batteries.............................16
Remote control operating range .................................17
Preparing the Projector
Installing the Projector ..................................... 19
Installation Methods ...........................................19
Installation methods .........................................19
Screen Size and Approximate Projection Distance.......................20
Connecting Equipment ..................................... 22
Connecting a Computer .........................................22
Connecting Image Sources .......................................23
Connecting USB Devices.........................................25
Connecting External Equipment...................................26
Connecting a LAN Cable (EB-925/EB-915W/EB-905/EB-96W/EB-95 only) . . . . . . . . 27
Installing the Wireless LAN Unit .................................... 28
Basic Usage
Projecting Images ......................................... 30
From Installation to Projection.....................................30
Automatically Detect Input Signals and Change the Projected Image (Source Search)
..........................................................31
Switching to the Target Image by Remote Control.......................32
Projecting with USB Display......................................32
System requirements ......................................... 32
Connecting for the first time....................................33
Uninstalling...............................................34
Adjusting Projected Images ................................ 36
Correcting Keystone Distortion.................................... 36
Correcting automatically (Auto V-Keystone).........................36
Correcting manually (manual H/V-Keystone).........................36
Correcting manually (Quick Corner)...............................37
Adjusting the Image Size ........................................39
Adjusting the Image Position .....................................39
Adjusting the Horizontal Tilt ......................................39
Correcting the Focus...........................................40
Adjusting the Volume..........................................40
Selecting the Projection Quality (Selecting Color Mode)...................40
Setting Auto Iris..............................................41
Changing the Aspect Ratio of the Projected Image ......................42
Changing methods ..........................................42
Changing the aspect mode (EB-915W/EB-910W/EB-96W only).............42
Changing the aspect mode (EB-925/EB-905/EB-900/EB-95 only) . ...........43
Contents
3

Epson EB-915W Specifications

General

Projection distance	1.79 - 2.92 m
Projection technology	LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	29 - 280 \
Projector native resolution	WXGA (1280x800)
Interface	USB
Aspect ratio	16:10
RS-232 ports	1
Dimensions (WxDxH)	263 x 345 x 93 mm
Connectivity technology	Wired
Lamp type	UHE
Lamp power	230 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Focus	Manual
Focal length range	18.2 - 29.2 mm
Analog signal format system	NTSC, PAL, SECAM
RMS rated power	16 W
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	2
Wi-Fi	-
Noise level	37 dB
Country of origin	China
Product type	Standard throw projector
Power consumption (standby)	0.39 W
Power consumption (typical)	337 W
Pallet width	800 mm
Pallet height	2190 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	48 pc(s)
Quantity per pallet (UK)	72 pc(s)
Quantity per pallet layer	4 pc(s)
Quantity per pallet layer (UK)	6 pc(s)

Weight and Dimensions

Weight	3400 g
Package depth	486 mm
Package width	358 mm
Package height	170 mm
Package weight	5060 g
