Epson EH-TW7300 User Manual

Maintenance
105
Maintenance
Cleaning the Parts
You should clean the projector if it becomes dirty or if the quality of projected images starts to deteriorate.
Warning
Do not use sprays that contain flammable gas to remove dirt and dust from the projector's lens, air filter,
and so on. The projector may catch fire due to the high internal temperature of the lamp.
Cleaning the air filter
Clean the air filter if dust has accumulated on the air filter or when the following message is displayed.
"The projector is overheating. Make sure nothing is blocking the air vent, and clean or replace the air
filter."
Attention
•
If dust collects on the air filter, it can cause the internal temperature of the projector to rise, and this can lead
to problems with operation and shorten the optical engine's service life. It is recommended that you clean
the air filter at least once every three months. Clean them more often than this if using the projector in a
particularly dusty environment.
•
Do not rinse the air filter in water. Do not use detergents or solvents.
•
Lightly brush the air filter to clean it. If it is brushed too strongly, dust will be ground into the air filter and
cannot be removed.
a
Press the button on the remote
control or the
button on the
control panel to turn off the power,
and then disconnect the power cord.
b
Remove the air filter cover.
Hook your finger into the tab on the air filter
cover, and remove it from the lens side.
c
Remove the air filter.
Grip the knob in the center of the air filter
and pull it out.

Epson EH-TW7300 Specifications

General

Matrix size	0.74 \
Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	3 - 6.3 m
Projection technology	3LCD
Supported aspect ratios	4:3, 16:10
Contrast ratio (typical)	160000:1
Screen size compatibility	50 - 300 \
Projection distance (wide)	3 - 6 m
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	± 30 °
Full HD	Yes
Color modes (2D)	Bright cinema, Cinema, Dynamic, Natural
Color modes (3D)	Cinema, Dynamic
Video processing	10 bit
Supported 3D formats	Side by side, Top and bottom
Analog signal format system	-
Supported graphics resolutions	640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 600 (SVGA), 1152 x 864 (XGA+), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160
Focus	Auto
Focal length range	22.5 - 46.7 mm
Lamp power	250 W
Light source type	Lamp
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Noise level	20 dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Serial interface type	RS-232
USB 2.0 ports quantity	2
S-Video inputs quantity	0
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.35 W
Power consumption (typical)	355 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Ethernet LAN data rates	10, 100 Mbit/s
Pallet width	800 mm
Pallet height	4630 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	16 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	450 mm
Width	520 mm
Height	170 mm
Weight	11000 g
Package depth	660 mm
Package width	515 mm
Package height	260 mm
Package weight	14384 g
