Epson EH-TW7300 User Manual

Contents
3
Organization of the Guide and
Notations in the Guide
Using Each Guide ..................... 1
Notations Used in This Guide ........... 2
Safety Indications.......................2
General Information Indications .............2
About the Use of "This Product" or "This Projector" 2
Introduction
Part Names and Functions ............. 6
Front/Top ............................. 6
Control Panel .......................... 7
Remote Control ......................... 9
Rear ................................ 12
Base ................................ 13
Preparing
Installing ............................ 14
Projected Image and Position of Projector.....14
Installing in parallel with the screen ........ 14
Installing the projector horizontally by
adjusting the height of either side ......... 14
Various Setting Methods.................15
Placing on a table and projecting.........15
Suspending from the ceiling and projecting . . 15
Projection Distance and Lens Shift Maximum
Values ............................... 16
Connecting a Device ................. 19
Removing the Terminal Cover .............. 19
Connecting Video Equipment ..............19
Connecting a Computer .................. 19
Connecting External Equipment............ 20
Connecting to the Trigger Out port ........20
Connecting WirelessHD devices (EH-
TW9300W/EH-TW8300W only)...........20
Connecting to the LAN port............. 21
Attaching the Wireless LAN unit............21
Connecting an HDMI Cable Clamp ........... 22
Preparing the Remote Control ........ 23
Installing the Remote Control Batteries.......23
Remote Control Operating Range ...........23
Operating range (left to right) ............ 24
Operating range (top to bottom) .......... 24
Basic Operations
Projecting Images ................... 25
Turning On the Projector.................25
If the target image is not projected . . . . . . . . 26
Using the Home Screen .................. 26
Turning Off ........................... 27
Adjusting the Projected Image . . . . . . . . 28
Displaying the Test Pattern ................ 28
Lens Adjustment Function (Focus, Zoom, Lens
Shift) ................................ 28
Adjusting the focus ................... 29
Adjusting the projection size (Zoom
Adjustment) ........................29
Adjusting the position of the projected
image (Lens Shift Adjustment)...........30
Adjusting the Projector's Tilt ...............31
Correcting Keystone Distortion ............. 31
Hiding the Image Temporarily .............. 31
Adjusting the Image
Adjusting the Image ................. 32
Selecting the Projection Quality (Color Mode) . . 32
Switching the Screen Between Full and Zoom
(Aspect)............................. 33
Adjusting the Sharpness .................. 34
Adjusting Image Resolution (Image
Enhancement) ......................... 35
Setting Auto Iris ........................36
Setting Frame Interpolation...............36
Adjusting the Color .................. 37
Adjusting the Color Temp.................37
Adjusting the RGB (Offset and Gain).........37
Adjusting Hue, Saturation, and Brightness . . . . . 37
Adjusting the Gamma ...................39
Select and adjust the correction value......39
Adjust while viewing the image..........39
Adjust using the gamma adjustment graph . . 40

Epson EH-TW7300 Specifications

General

Matrix size	0.74 \
Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	3 - 6.3 m
Projection technology	3LCD
Supported aspect ratios	4:3, 16:10
Contrast ratio (typical)	160000:1
Screen size compatibility	50 - 300 \
Projection distance (wide)	3 - 6 m
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	± 30 °
Full HD	Yes
Color modes (2D)	Bright cinema, Cinema, Dynamic, Natural
Color modes (3D)	Cinema, Dynamic
Video processing	10 bit
Supported 3D formats	Side by side, Top and bottom
Analog signal format system	-
Supported graphics resolutions	640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 600 (SVGA), 1152 x 864 (XGA+), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160
Focus	Auto
Focal length range	22.5 - 46.7 mm
Lamp power	250 W
Light source type	Lamp
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Noise level	20 dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Serial interface type	RS-232
USB 2.0 ports quantity	2
S-Video inputs quantity	0
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.35 W
Power consumption (typical)	355 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Ethernet LAN data rates	10, 100 Mbit/s
Pallet width	800 mm
Pallet height	4630 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	16 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	450 mm
Width	520 mm
Height	170 mm
Weight	11000 g
Package depth	660 mm
Package width	515 mm
Package height	260 mm
Package weight	14384 g
