Epson EH-TW7300 User Manual

Configuration Menu
88
Basic menu
Function Menu/Settings Explanation
Projector Name
Up to 16 alphanumeric
characters
Enter a name to identify the projector over a network.
PJLink Password
Up to 32 alphanumeric
characters
Set a password to use when you control the projector using
compatible PJLink software.
s p.116
Remote Password
Up to 8 alphanumeric
characters
Set a password to use when you operate the projector from
a smartphone or a tablet.
Display LAN Info.
Text & QR Code, Text Set the display format for the projector's network information.
Wireless LAN menu
Function Menu/Settings Explanation
Connection Mode
Quick, Advanced Determines how the wireless LAN is connected.
Quick: Lets you connect to multiple smartphones, tablets, or
computers directly using wireless communication. Use
EasyMP MultiPC Projection to connect in this connection
mode. The projector acts as an easy access point.
(We recommend limiting the number of devices to six or less
to maintain the projection performance.)
Advanced: Lets you connect to multiple smartphones, tab-
lets, or computers over a wireless network access point.
Channel
1ch, 6ch, 11ch
(This can only be set when Connection Mode is set to Quick.)
Select the frequency bandwidth used by the wireless LAN.
SSID
Up to 32 alphanumeric
characters
(This can only be set when Connection Mode is set to Ad‐
vanced.)
Enter an SSID. When an SSID is provided for the wireless LAN
system in which the projector participates, enter the SSID.
Search Access Point
To Search View
(This can only be selected when Connection Mode is set to
Advanced.)
Search for available wireless network access points.
indicates currently connected access points. indicates
the access points where security is set.
If you select an access point which has security, Security menu
appears.
s p.89
IP Settings
(This can only be set
when Connection
Mode is set to Ad‐
vanced.)
DHCP Sets whether or not to use DHCP (On or Off). If this is set to
On, you cannot set any more addresses.
IP Address Inputs the IP address for the projector.
The following IP addresses cannot be used.
0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a
number from 0 to 255)
Subnet Mask Inputs the subnet mask for the projector.
The following subnet masks cannot be used.
0.0.0.0, 255.255.255.255
Gateway Address Inputs the gateway IP address of the projector.
The following gateway addresses cannot be used.
0.0.0.0, 127.x.x.x, 224.0.0.0 to 255.255.255.255 (where x is a
number from 0 to 255)

Epson EH-TW7300 Specifications

General

Matrix size	0.74 \
Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	3 - 6.3 m
Projection technology	3LCD
Supported aspect ratios	4:3, 16:10
Contrast ratio (typical)	160000:1
Screen size compatibility	50 - 300 \
Projection distance (wide)	3 - 6 m
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	± 30 °
Full HD	Yes
Color modes (2D)	Bright cinema, Cinema, Dynamic, Natural
Color modes (3D)	Cinema, Dynamic
Video processing	10 bit
Supported 3D formats	Side by side, Top and bottom
Analog signal format system	-
Supported graphics resolutions	640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 600 (SVGA), 1152 x 864 (XGA+), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 960, 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160
Focus	Auto
Focal length range	22.5 - 46.7 mm
Lamp power	250 W
Light source type	Lamp
Service life of light source	3500 h
Service life of light source (economic mode)	5000 h
Noise level	20 dB
Country of origin	China
2D/3D frequency image	240/480 Hz
Serial interface type	RS-232
USB 2.0 ports quantity	2
S-Video inputs quantity	0
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.35 W
Power consumption (typical)	355 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Ethernet LAN data rates	10, 100 Mbit/s
Pallet width	800 mm
Pallet height	4630 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pack	1 pc(s)
Quantity per pallet	16 pc(s)
Quantity per pallet layer	2 pc(s)

Weight and Dimensions

Depth	450 mm
Width	520 mm
Height	170 mm
Weight	11000 g
Package depth	660 mm
Package width	515 mm
Package height	260 mm
Package weight	14384 g
