Epson EX7210 User Manual

To change settings for an input source, make sure the source is connected and select that source.
Setting Options Description
Color Mode See the list of available Color Adjusts the vividness of image
Modes colors for various image types
and environments
Brightness Varying levels available Lightens or darkens the overall
Contrast Varying levels available Adjusts the difference between
light and dark areas of the image
Color Saturation Varying levels available Adjusts the intensity of the image
colors
Tint Varying levels available Adjusts the balance of green to
magenta tones in the image
Sharpness Varying levels available Adjusts the sharpness or
softness of image details
Color Temp. (color temperature) High Sets the overall color tone; High
tints the image blue and Low
Medium
tints the image red
Low
77

Epson EX7210 Specifications

Projection Specifications

projection_system	3LCD, 3-chip technology
projection_method	Front/rear/ceiling mount
native_resolution	1280 x 800 (WXGA)

Light and Lamp

color_light_output	2800 lumens
white_light_output	2800 lumens
lamp_type	200 W UHE

Power

power_supply_voltage	100 – 240 V ±10%, 50/60 Hz
power_consumption_eco_mode	234 W
power_consumption_normal_mode	283 W

Operating Environment

operating_temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan_noise_eco_mode	29 dB
fan_noise_normal_mode	37 dB

Lens

f_number	1.58 - 1.72
focal_length	16.9 mm – 20.28 mm
zoom_ratio	Digital zoom 1.0 – 1.2

Weight and Dimensions

dimensions_excluding_feet	11.6" x 9.0" x 3.0"
dimensions_including_feet	11.6" x 9.0" x 3.1"
weight	5.1 lb
