Disassembly/Reassembly Overview 24
L365/L366,L360/L362,L310/L312,L220/L222,L130/L132 Series Revision A
Ink Supply Tank (Cyan) 4:11 --- 4:11
Ink Supply Tank (Black)
4:11 --- 4:11
Ink Supply Tank Tube Assy
3:30 --- 3:30
Tube Guide Sheet Sub
0:30 --- 0:30
Tube Pressing Plate
0:52 --- 0:52
Ink Supply Tube Guide 1st
0:06 --- 0:06
Ink Supply Tube Guide 2nd
3:25 --- 3:25
Joint
2:20 --- 2:20
Adapter Cover
0:37 --- 0:37
Ink Supply Tube Assy
2:11 --- 2:11
Tube Guide Sheet
1:39 --- 1:39
Adapter
1:49 --- 1:49
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total

Epson L222 Specifications

General

Print Technology	On-demand inkjet (Piezoelectric)
Print Resolution	5760 x 1440 dpi
Minimum Ink Droplet Size	3 pl
Print Speed (Black)	33 ppm
Print Speed (Color)	15 ppm
Copy Function	Yes
Ink Tank System	Yes
Ink Bottle Capacity (Black)	70 ml
Output Paper Capacity	30 sheets
Connectivity	USB 2.0
Weight	4.4 kg
Scanner Type	Flatbed colour image scanner
Ink Bottle Capacity (Color)	70 ml (Cyan, Magenta, Yellow)
Paper Sizes Supported	A4, A5, A6, B5, Letter, Legal
Paper Capacity	100 sheets (A4 plain paper)
Operating System Compatibility	Windows XP / Vista / 7 / 8 / 8.1, Mac OS X
Input Paper Capacity	100 sheets (A4 plain paper)
